Place of Origin:
Xi'an,China
Brand Name:
FHH
Grade 5 titanium (Ti6Al4V) is the most widely utilized titanium alloy, renowned for its exceptional mechanical properties and versatility across various industries. This alloy contains 90% titanium, 6% aluminum, and 4% vanadium, which contribute to its remarkable strength and resistance to corrosion. Primarily, Grade 5 titanium is used in aircraft engine components due to its high strength-to-weight ratio, allowing for enhanced performance and fuel efficiency. Its applications extend beyond aviation to include structural parts in rockets, missiles, and high-speed aircraft, making it a critical material in the aerospace sector.
Since the mid-1960s, titanium and its alloys have found extensive use in diverse industries. The electrolysis industry utilizes titanium in the production of electrodes, benefiting from its corrosion resistance and durability. Additionally, power stations rely on titanium for condensers, while petroleum refining and seawater desalination processes often incorporate titanium heaters due to their ability to withstand harsh environments. Furthermore, titanium is employed in environmental pollution control devices, reflecting its versatility and importance in sustainable practices. With its excellent corrosion resistance, titanium has become a preferred choice for structural applications where durability and longevity are essential.
Gr5 Titanium Alloy Bar Specifications
Gr5 titanium alloy bars are available in various grades tailored to meet specific industry needs: industrial, medical, and aviation. While the chemical compositions of these grades are similar, their physical properties differ significantly, allowing for a wide range of applications. We offer products customized to customer specifications, ensuring that every requirement is met.
Material: Gr5 Titanium
Standards: ASTM B348, AMS 4928, ASTM F136
Diameters Available: 5mm to 50mm (with various sizes such as 6mm, 8mm, 10mm, 12mm, etc.)
Max Length: 6000mm
Supply Condition: Annealed
Applications: Industrial, aviation, medical, and other sectors
Packaging: Carton or plywood case
Quality Certification: EN10204.3.1
Surface Finish: CNC machined and polished
Titanium rods offer numerous advantages over traditional materials like steel and aluminum. Here are some key benefits:
Strength: Titanium boasts a very high strength-to-weight ratio, meaning it is stronger than steel while remaining significantly lighter. This property is particularly beneficial in applications where reducing weight is critical, such as in aerospace and automotive industries.
Corrosion Resistance: The natural oxide layer on titanium provides exceptional resistance to corrosion. This feature enables titanium to perform reliably in harsh environments, including marine and chemical applications, where other materials might degrade quickly.
Biocompatibility: One of titanium's standout properties is its biocompatibility. It is non-toxic and does not induce adverse reactions in the human body, making it a preferred material for medical implants, dental devices, and prosthetics. Its use in healthcare continues to expand, driven by its safety and effectiveness.
Non-magnetic: Titanium is inherently non-magnetic, making it an ideal choice for applications in medical equipment, such as MRI machines, where magnetic interference could disrupt functionality. This property is crucial in ensuring the safety and accuracy of medical imaging.
Aesthetics: Titanium has a unique and attractive appearance that makes it popular in jewelry and decorative applications. Its lustrous finish and ability to take on vibrant colors through anodization have made titanium a fashionable choice for high-end accessories.
Durability: Titanium is highly resistant to wear and tear, significantly outlasting many other materials. This durability translates to lower maintenance costs and longer service life in various applications, from industrial machinery to consumer goods.
In summary, Grade 5 titanium alloy bars are an invaluable resource across multiple industries, combining strength, corrosion resistance, and versatility. Their unique properties make them suitable for a wide array of applications, including aerospace, medical, and industrial fields. As industries continue to seek materials that offer both performance and reliability, titanium, especially Grade 5, will remain a top choice for engineers and manufacturers alike. With the ability to customize products to meet specific needs, our offerings ensure that customers receive the best solution for their unique challenges, reinforcing the critical role of titanium in modern engineering and manufacturing.
Gr 5 titanium alloy bar / rod Chemical Composition
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
Gr 5 titanium bar / rod Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 |
Psi – 128000 , MPa – 880 |
14 % |
Equivalent Grades for Gr 5
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 5 | 3.7165 |
N56400
|
Titanium rods offer numerous advantages over traditional materials like steel and aluminum. Here are some key benefits:
Biocompatibility: One of titanium's standout properties is its biocompatibility. It is non-toxic and does not induce adverse reactions in the human body, making it a preferred material for medical implants, dental devices, and prosthetics. Its use in healthcare continues to expand, driven by its safety and effectiveness.
Non-magnetic: Titanium is inherently non-magnetic, making it an ideal choice for applications in medical equipment, such as MRI machines, where magnetic interference could disrupt functionality. This property is crucial in ensuring the safety and accuracy of medical imaging.
Strength: Titanium boasts a very high strength-to-weight ratio, meaning it is stronger than steel while remaining significantly lighter. This property is particularly beneficial in applications where reducing weight is critical, such as in aerospace and automotive industries.
Corrosion Resistance: The natural oxide layer on titanium provides exceptional resistance to corrosion. This feature enables titanium to perform reliably in harsh environments, including marine and chemical applications, where other materials might degrade quickly.
Durability: Titanium is highly resistant to wear and tear, significantly outlasting many other materials. This durability translates to lower maintenance costs and longer service life in various applications, from industrial machinery to consumer goods.
Aesthetics: Titanium has a unique and attractive appearance that makes it popular in jewelry and decorative applications. Its lustrous finish and ability to take on vibrant colors through anodization have made titanium a fashionable choice for high-end accessories.
| Name | Material | Shape | Surface | Standards | Grade |
|---|---|---|---|---|---|
| Titanium Bar / Titanium Rod | Titanium Metal Or Alloy | Square, round, Hexagonal | Polished, Sandblasted, Anodized, black, picking Sand-blasting | ASTM B348, ASME SB348, ASTM F67, ASTM F136, AMS4928, AMS2631b | Gr1, Gr2, 3, 4, 5, 9, 12 |
Orthopedic implants include artificial joints, metal plates, orthopedic nails, metal orthopedic use rods, intramedullary nails, bone needles, and spinal fixation devices.
Heart medicine implants are also available, such as artificial heart valves, cardiac pacemakers, cardiac catheters and stents within blood vessels.
Ophthalmic implants consist of artificial crystals while dental implants include dental implants, traction nails, nail plant root canal, and internal fixation devices, among others.
Moreover, there are also available filling materials for breast filling, intraocular filling materials, and filling materials in orthopedics.
