Place of Origin:
Xi'an,China
Brand Name:
FHH
The company has the first large diameter titanium tube continuous production line in Asia, 1120 machines, and 30 machines /40 machines /45 machines /60 machines /90 machines and other continuous pipeline 7, using plasma + argon arc welding (P+T) straight seam welding technology, can process and produce the wall thickness of 0.35mm-10mm, diameter of 8mm-426mm titanium tubes; And has universal testing machine, ultrasonic inspection, eddy current inspection, underwater airtight and other testing equipment.
The company produces titanium welded pipes in strict accordance with the Chinese national standard GB/T3625 and the American standard ASTM B338. The product specifications include (diameter 8mm-1016mm, wall thickness 0.35mm-60mm), of which φ8mm-φ426mm can be produced online. Titanium welded pipes Φ80-φ159 and other specifications are widely used in automobile exhaust pipes, and the products are exported to Southeast Asia, the United States and Europe and other international markets; φ8-φ45 small-diameter welded pipes are widely used in refrigeration and heating industries such as condensers and heat exchangers. Other specifications titanium and nickel-based alloy welded pipe is widely used in aerospace, petrochemical, power engineering, seawater desalination, environmental protection equipment, daily necessities and other fields.
| Item | Standard | Material | Size(mm) |
|
Heat exchanger And Condenser tube |
ASTMB338,ASTMB337, ASTMB861 |
Grade1,2,3 | OD(5-114)X(0.3—10)XL1200mmMax |
| Corrosion Resistant Tubes | ASTMB338 | Grade7,Grade12 | OD(5-114)X(0.5—4.5)Xlength 12000mmMax |
| BikeFrame/Wheelchair/Exhaust tube/Pipes |
ASTMB338 |
Gr9/Ti3Al2v5 | OD(38.1—44.5)X(0.9-3.15)X(L1000—2000MM) |
| Automobile&MotorCycle Exhaust Tube/Pipes | ASTMB337/338 | Gr1,Gr2,Gr9 | OD(38.1—88.9)X1.2X(L1000—2000mm) |
| Marine Industry | ASTM/AMS | Gr2,Gr5,Gr7,Gr12 | OD(23.1-210)X(W0.5-6.0)X(L1000-6000mm) |
Any oreder,Please state your request in details,Such as :Quantity,Dimension(Length,High,thickness,wideth,or fixed length),Materials,Standard etc.
