Titanium is renowned for its exceptional properties, making it an indispensable material across various industries. Among the different grades of titanium, ASTM B265 Grade 2 and Grade 5 (Ti-6Al-4V) are two of the most widely utilized forms. Both grades exhibit unique characteristics that cater to specific applications, particularly in aerospace, marine, chemical processing, and medical fields. This article delves into the properties, applications, and advantages of these titanium plates, highlighting their significance in modern engineering.
ASTM B265 Grade 2 titanium is categorized as a commercially pure titanium grade, comprising at least 99% titanium with trace amounts of other elements. This high purity level contributes to its excellent corrosion resistance, making it suitable for challenging environments, especially in the chemical industry and marine applications. Grade 2 titanium exhibits a combination of good strength and ductility, allowing it to be formed and welded easily, which is crucial for manufacturing processes.
The tensile strength of Grade 2 titanium is typically around 345 MPa (50,000 psi), with a yield strength of approximately 275 MPa (40,000 psi). These mechanical properties make it ideal for applications where moderate strength is required, coupled with outstanding corrosion resistance. Additionally, its low density contributes to weight reduction in structures, which is particularly beneficial in industries like aerospace, where minimizing weight is critical for performance and fuel efficiency.
On the other hand, ASTM B265 Grade 5 titanium, also known as Ti-6Al-4V, is an alloy that combines titanium with aluminum and vanadium. This composition significantly enhances the mechanical properties of the material. Grade 5 titanium boasts a tensile strength of up to 180 kg/mm² (1,800 MPa), making it nearly twice as strong as Grade 2. The addition of aluminum and vanadium not only improves strength but also lowers the elastic modulus, resulting in improved flexibility and formability.
Grade 5 titanium’s remarkable strength-to-weight ratio has earned it the nickname "space metal," and it is extensively employed in the aerospace sector. Its ability to withstand high temperatures and stresses makes it suitable for critical applications, from aircraft components to spacecraft. Furthermore, Grade 5 titanium retains excellent corrosion resistance, similar to that of commercially pure grades, ensuring durability even in aggressive environments.
Both ASTM B265 Grade 2 and Grade 5 titanium plates find extensive applications in the aerospace industry. Grade 2 is often used in areas that require lightweight materials with good corrosion resistance, such as airframe components, engine parts, and fasteners. Its ability to be easily welded and fabricated further enhances its utility in complex structures.
Conversely, Grade 5 titanium is preferred in high-performance applications where strength is paramount. This includes critical components in jet engines, landing gear, and structural frames. Additionally, in the marine industry, both grades are utilized for seawater applications due to their exceptional resistance to saltwater corrosion. Grade 5, with its higher strength, is often chosen for propeller shafts and hull fittings, while Grade 2 may be used for piping and pressure vessels.
The chemical industry also benefits greatly from the use of titanium plates, particularly ASTM B265 Grade 2. Its resistance to a wide range of corrosive substances, including acids and chlorides, makes it an ideal choice for heat exchangers, reactors, and storage tanks. Grade 2’s capability to maintain its integrity in harsh environments ensures safety and reliability, reducing the need for frequent replacements.
In the medical field, titanium alloys have gained popularity for their biocompatibility, particularly Grade 5. Its excellent compatibility with human tissue has led to its use in artificial implants, including orthopedic devices and dental fixtures. The strength and lightweight nature of Grade 5 titanium are particularly advantageous in load-bearing applications, where reducing the overall weight can contribute to better patient outcomes.
Manufacturing titanium plates, whether Grade 2 or Grade 5, involves specific considerations to ensure quality and performance. The production process typically includes forging, rolling, and heat treatment, which help achieve the desired mechanical properties. Maintaining strict control over the production environment is essential to prevent contamination, as titanium is sensitive to impurities.
Welding techniques also play a crucial role in the fabrication of titanium plates. Both grades require specialized welding methods, such as TIG (Tungsten Inert Gas) welding, to preserve their mechanical properties. Adequate shielding from atmospheric contaminants during welding is critical to prevent defects like embrittlement or reduced corrosion resistance.
While titanium plates are generally more expensive than traditional metals like steel or aluminum, their long-term benefits often justify the initial investment. The durability and corrosion resistance of titanium lead to reduced maintenance costs and longer service life, particularly in demanding environments. Moreover, as industries increasingly prioritize sustainability, titanium’s recyclability enhances its appeal. Used titanium can be reprocessed and repurposed, minimizing waste and promoting environmental responsibility.
In conclusion, ASTM B265 Grade 2 and Grade 5 titanium plates are vital materials in a variety of industries, offering distinct advantages based on their unique properties. Grade 2 excels in applications requiring excellent corrosion resistance and moderate strength, while Grade 5 is favored for its superior strength and versatility in high-performance settings. As technology advances and the demand for lightweight, durable materials grows, the importance of these titanium grades will continue to rise, driving innovation across multiple sectors. Their significant contributions to aerospace, marine, chemical, and medical applications underscore the vital role titanium plays in modern engineering and manufacturing.
Titanium Plate is a high heat-resistant, lightweight, and corrosion resistant material, making it ideal for a variety of aerospace, chemical, and medical applications. It comes in a variety of grades and finishes, including Gr1, Gr2, Gr3, Gr4, Gr5, Gr6, Gr7, Gr10, and can be polished, mill finished, pickled, painted, brushed or blasted, all in a silver finish. This versatile titanium alloy sheet is perfect for sheet metal fabrication, offering both excellent formability and weldability. With its superior strength-to-weight ratio, titanium sheet metal is an ideal choice for any lightweight application.
We can supply a broad selection of titanium sheets and plates for fabrication and engineering applications. Sheets can be cut precisely according to your needs and are available in a variety of surface finishes. We adhere to the following production standards: ASTM B265, AMS 4920, ASME SB265, ASTM SB 265, and DIN 17860.
The titanium grades we offer include Gr1, Gr2, Gr10 or 5(6Al-4V), 7(Ti-0.15Pd), 9(3Al-2.5V), and so on.
Titanium Sheet and Plate
We can supply a wide selection of titanium sheets and plates for fabrication and engineering projects. They can be precision-cut to your specifications and come with a selection of surface finishes.
Production Standards:
Sheets and plates follow ASTM B265, AMS 4920, ASME SB265, ASTM SB 265, and DIN 17860 specifications.
Titanium Grades:
Grades available include Gr1, Gr2, Gr10 or 5 (6Al-4V), 7 (Ti-0.15Pd), 9 (3Al-2.5V), etc.
Titanium Sheet Surface Finishes:
Recommended finishes for titanium sheet include polished, mill, pickling, painted, brushed, or blasted.
| Apart from the products listed below, other available metal products are not listed here. Other metal products USTi can manufacture and supply include Tantalum, Niobium, Zirconium, Hafnium, Nickel, Copper etc., which are mainly in the form of Plate, Bar and Tube. | |||
| Products | Processing Standard | Grade | Size |
| Titanium Plate, Sheet, Coil | ASME SB265, AMS 4911, AMS 4919, AMS 4914 ASTM F67, ASTM F136 |
GR1, GR2, GR3, GR4, GR5, GR7, GR9, GR12, GR16, GR17, GR23, Ti-6Al-4V ELI, Ti-6-2-4-2, Ti-15-3-3-3 |
Thickness: (0.0197”-6”) Max Width: 12 feet Max Length: 50 feet |
|
Titanium Foil |
ASME SB265 |
GR1, GR2, GR5
|
(0.001”-0.004”) x 4.8” x coil (0.004”-0.01”) x 18” x coil (0.012”-0.0158”) x 48” x coil |
Titanium Plates, produced by FHH from Xi'an, China, are available in a minimum order quantity of 200kgs and are packed for seaworth shipment materials for delivery within 5-8 days. Payment options such as L/C, D/P, T/T are accepted, and the supply ability is 1000pcs/month. The product has excellent corrosion resistance and meets standards such as ASTM B265, AMS 4920, ASME SB265, ASTM SB 265, DIN 17860, GB, JS. The technology used in its production is either cold rolling or hot rolling, and it offers high resistance to heat. Its surface can be polished, milled, pickled, painted, brushed, or blasted.
Titanium Plate provides technical support and service to its customers through a comprehensive range of support options.
Customers can access technical support and service by contacting Titanium Plate's customer service team directly. Our team is available to answer any questions or concerns, provide product and technical support, and provide helpful guidance. Our team can be contacted by phone, email, or live chat.
In addition, Titanium Plate provides customers with online access to product and user guides, tutorials, frequently asked questions, and access to our knowledge base. This helps customers quickly and easily find solutions to their questions or issues.
We also provide customers with access to our online forums. Here customers can discuss product features, ask questions, and offer feedback. Our forums are moderated by our team to ensure customers receive the support they need.
Packaging and Shipping for Titanium Plate:
Titanium plate will be packaged in shrink-wrapped pallets with cardboard separators to ensure the product is not damaged during shipping. The pallets will then be shrink-wrapped and secured with plastic straps to ensure the product is even more secure. The pallets will then be loaded onto a truck or freight train for shipping to the desired location.
